When most people think about HVAC filtration, they think about the filter itself — the MERV rating, the brand, the size. But behind every high-performing filtration system is something that rarely gets the spotlight: the housing. The right housing is the difference between a filter that performs to its rated efficiency and one that leaks bypass air around the frame, drops pressure unevenly, and forces costly change-outs.

For commercial buildings, hospitals, manufacturing plants, data centers, and government facilities, the housing is where filtration performance, code compliance, and long-term operating cost are decided. This guide walks through the major housing types, when each one fits, and how to spec a system that will still be doing its job 20 years from now.

Why the Housing Matters More Than People Think

A filter is only as good as the seal around it. If conditioned air can bypass the filter through gaps in the frame, gasket failures, or poorly designed access panels, even a MERV 16 filter ends up performing closer to a MERV 8. Industry studies have consistently shown that bypass leakage can reduce real-world filtration efficiency by 25% or more, which directly affects occupant health, equipment longevity, and energy bills.

A well-engineered housing solves three problems at once:

• Airtight performance — gasketed or gel-seal frames eliminate bypass and keep filter efficiency where it should be.
• Code compliance — OSHA, NFPA, and ASHRAE standards have specific requirements for housings used in commercial and critical environments.
• Maintenance access — side-access doors, crank-lock mechanisms, and quick-change tracks cut filter change-out labor dramatically over a building's life.

The Six Housing Types Every Spec Writer Should Know

Most commercial and industrial filtration projects use one of six housing configurations. Each is built for a specific combination of efficiency level, available space, and operating environment.

1. Flat Bank ASHRAE Housing

The most compact option, designed for single- or multi-stage ASHRAE filtration where space is tight — ducts, packaged AHUs, or rooftop units where a deeper V-bank simply won't fit. Flat bank housings work best when face velocity is moderate and you don't need to maximize filter face area.

Best fit: light commercial buildings, retrofits in existing duct sections, mechanical rooms with limited clearance.

2. V-Bank ASHRAE Housing

By arranging filters in a V configuration, this housing roughly doubles the filter face area within the same footprint as a flat bank. The result is lower pressure drop, longer filter life, and reduced fan energy. V-bank housings are the workhorse of commercial and industrial filtration where energy efficiency and long change-out intervals matter.

Best fit: mid- to large-scale commercial buildings, industrial process air, facilities running 24/7 where fan energy is a major operating cost.

3. Side Access ASHRAE Housing

A versatile 2-stage housing with multiple depth options and customizable tracks for combining a prefilter and a final filter in a single unit. Side access doors make filter changes faster and safer because technicians don't have to disassemble ductwork or enter confined spaces.

Best fit: demanding HVAC systems where staged filtration extends the life of expensive final filters — typical in hospitals, labs, schools, and government buildings.

4. HEPA Crank-Lock Housing

Engineered for true HEPA filtration (99.97% efficient at 0.3 microns) where airtight sealing is non-negotiable. The crank-lock mechanism compresses the filter against a gasket or gel seal with consistent, repeatable force every time, eliminating the inconsistent torque you get from manual clamps.

Best fit: hospital surgical suites and isolation rooms, pharmaceutical cleanrooms, semiconductor manufacturing, biosafety labs.

5. Bag-In/Bag-Out (B-I-B-O) Housing

The gold standard for environments where the filter media itself may be contaminated — radioactive, biological, or chemical hazards. B-I-B-O housings allow technicians to change filters using a sealed PVC bag, so the contaminated filter is never exposed to room air or the technician. These housings are built to ASME N510 standards.

Best fit: nuclear facilities, BSL-3 and BSL-4 labs, pharmaceutical containment, hazardous chemical processing, government and defense applications.

6. BioMAX Fan Filter Unit (FFU)

A self-contained ceiling-mounted unit combining a fan, motor, and HEPA filter into a single package. The BioMAX FFU runs at just 51 dBA, making it suitable for environments where occupant comfort and noise control matter — operating rooms, ICUs, compounding pharmacies. FFUs are also energy-efficient because each unit can be controlled independently.

Best fit: modular cleanrooms, hospitals, USP 797/800 compounding spaces, sensitive electronics manufacturing.

Matching Housings to Filter Efficiency

The filter and housing have to be designed as a system. Here's how the major Koch Filter product lines pair with the housings above:

Code Compliance: What ASHRAE, OSHA, and NFPA Require

Specifying a housing isn't just about performance — it's about meeting the standards that building inspectors, insurance carriers, and federal regulators will check against.

ASHRAE Standard 52.2 defines how filter efficiency is measured (the MERV rating system). For the rated MERV to mean anything in the field, the housing must prevent bypass — which is why ASHRAE-listed housings include gasketed sealing surfaces and certified leak rates.

ASHRAE Standard 170 governs ventilation for healthcare facilities and specifies minimum filtration efficiencies (typically MERV 14 prefilter plus HEPA final) along with housing performance requirements.

OSHA regulates worker exposure to airborne contaminants in industrial settings. For processes generating dust, fumes, or chemicals, OSHA may require source-capture filtration with housings rated for the contaminant being controlled.

NFPA 90A and 90B govern fire safety in air-handling systems, including requirements for housing materials, access doors, and smoke/fire damper integration.

ASME N510 is the testing standard for nuclear-grade containment housings (the B-I-B-O type), and it's increasingly referenced for high-containment biological applications.

A Spec-Writer's Checklist for New Builds and Retrofits

Lead Times and Sourcing

Koch Filter operates four strategically located U.S. manufacturing facilities, which means lead times on filters and housings are typically better than overseas-sourced alternatives. For new construction projects on tight schedules, this matters: a housing delay can hold up commissioning, certificate of occupancy, and tenant move-in.

As an authorized Koch Filter dealer, RememberTheFilter.com handles spec review, quoting, and project-scale orders for commercial, industrial, and government customers. Our team has 50+ years of combined HVAC filtration experience, and we'll work with your mechanical engineer or facility team to make sure the filter, housing, and replacement schedule all line up.

Bottom Line

The housing is the unsung hero of every high-performance filtration system. Get it right, and your filters deliver their full rated efficiency for years of service. Get it wrong, and you'll be paying for premium MERV ratings while breathing MERV 8 air. For any commercial, industrial, or government project where IAQ, code compliance, and long-term cost matter — and that's most of them — the housing deserves the same attention as the filter inside it.

Whether you're spec'ing a new build, planning a retrofit, or trying to solve a recurring filtration problem in an existing system, the right housing-filter combination is out there. Our team is here to help you find it.
