Designed for high performance under both normal and difficult operating conditions, VariCel II filters are appropriate for general HVAC and applications operating with variable air volume, turbulent airflow, and high humidity. The combination of durable construction and high efficiency also makes VariCel II filters ideal for specialized systems, such as diffusion filters in paint booths and prefilters in cleanrooms.
Heavy Duty Construction
High Performance in Tough Operating Conditions The frame is made with a 2-piece die cut contructed from high wet-strength beverage board. Two mating die cut boxes are bonded together, forming a double wall around the perimeter of the filter. The mini-pleat media pack is bonded inside the double wall. The double-walled frame prevents leakage and increases rigidity.
Slim-Line Design
The slim-line design of the VariCel II filters provides minimum resistance and maximum dust loading capacity while lowering operating costs. Rows of adhesive beads are used to maintain even pleat spacing and provide maximum airflow with minimal resistance. The consistent pleat spacing of the media allows higher dust holding capacity and full use of the entire depth of the media.
Dual-Density Media
Increases Dust Holding Capacity VariCel II filters use microglass paper media with a water repellent binder. The fibers are formed with dual-density construction, consisting of coarser fibers on the air entering side and finer fibers on the air leaving side. This design allows for collection of particulate throughout the full thickness of the media, substantially increasing dust holding capacity. The media is water repellent and can withstand intermittent exposure to water without affecting performance.
